CO2 laser for non-metal materi…
| Specification | CO2 Laser Marking Machine This model | DLM-CS-55 CO2 Split-type Laser Marking Machine | DLM-CS-30 CO2 Split-type Laser Marking Machine |
|---|---|---|---|
| Laser Source | CO2 Glass Tube / RF Metal | — | — |
| Power | 30W / 60W / 100W | — | — |
| Wavelength | 10.6μm | — | — |
| Marking Area | 110×110mm / 200×200mm | — | — |
| Material | Non-metals: Wood, Leather, Acrylic | — | — |
| dlm-cs-30 | — | DLM-CS-40 | — |
| Brand | — | JCZ - LV7 | JCZ - LV7 |
| 30w | — | 40W | — |
| Repetition Frequency | — | 0~25kHz | 0~25kHz |
| Beam Size | — | 1.8 ± 0.2mm | 1.8 ± 0.2mm |
| Power Adjustment Range | — | 10~100% | 10~100% |
| Marking Speed | — | ≤7000mm/s | ≤7000mm/s |
| Dual Red Light | — | Manual (Optional Dual Red Light Focusing) | Manual (Optional Dual Red Light Focusing) |
| Marking Range | — | 110*110mm (Optional 140*140mm / 175*175mm) | 110*110mm (Optional 140*140mm / 175*175mm) |
| Focal Length Height | — | F=150mm | F=150mm |
| Min Line Width | — | 0.1mm @ F=150mm (Differences In Materials) | 0.1mm @ F=150mm (Differences In Materials) |
| Min Character | — | 0.4mm @ F=150mm | 0.4mm @ F=150mm |
| Repeatability Accuracy | — | 0.1mm | 0.1mm |
| Software | — | Ezcad2,Compatible with LightBurn | Ezcad2,Compatible with LightBurn |
| Support System | — | Windows | Windows |
| Support File Formats | — | Jpg | Jpeg | Bmp | Gif | Png | Ai | Plt | Dxf | Svg | Jpg | Jpeg | Bmp | Gif | Png | Ai | Plt | Dxf | Svg |
| Software Language | — | Chinese | English | French | Russian| German | Italian |Korean | Japanese etc. | Chinese | English | French | Russian| German | Italian |Korean | Japanese etc. |
| Lifting Method | — | Manual Lifting (Optional Electric Lifting) | Manual Lifting (Optional Electric Lifting) |
| Computer | — | Not Included, Optional To Add | Not Included, Optional To Add |
| Cooling Method | — | Air Cooling | Air Cooling |
| Power Supply | — | 110~220V 50Hz~60Hz | 110~220V 50Hz~60Hz |
| Laser Wavelength | — | — | 10.6μm |
| Laser Power | — | — | 30W |
CE · ISO 9001 · FDA-compliant manufacturing
Full technical support & global service network
Best quote with free sample test & fast delivery
CO2 laser for non-metal materials — wood, leather, paper, acrylic, and more. Ideal for craft, packaging, and promotional products.
| Laser Source | CO2 Glass Tube / RF Metal |
|---|---|
| Power | 30W / 60W / 100W |
| Wavelength | 10.6μm |
| Marking Area | 110×110mm / 200×200mm |
| Material | Non-metals: Wood, Leather, Acrylic |
This machine can permanently mark most metals including steel, stainless steel, iron, aluminum, copper, brass, titanium, gold, silver, and hard alloys. It also works on ABS, PVC, PC, nylon, and other hard plastics.
The machine comes with EZCAD software (Windows) included at no extra cost. It is also compatible with LightBurn, a popular third-party laser control software.
Air-cooled models require no external water chiller — just plug into a standard power outlet. Cabinet models have built-in cooling fans.
Yes, you can upgrade the marking area by replacing the F-theta lens. We sell F-theta lenses separately and can guide you through installation.
Supported formats include PLT, DXF, AI, SVG, JPG, GIF, BMP, PNG, and more. Both vector and raster files are supported.
